Horizontal Filter Press / Zero Hold-up Sparkler Filter for Product Recovery

|

Horizontal Filter Press Technology

Horizontal Filter press also known as sparkler filters, widely used for various solid liquid separation application in the industry.

Salient Features of CleaNsep Horizontal Filter Press

Sparkler Filter for Horizontal Filter Press

Complete recovery of filtrate (practically zero hold up)
Uniform cake distribution over each plate
Complete cake retention on the plates
Single pass clear filtration
Less exposure to the operator
No contamination of the internal surface of the shell
For filtration at elevated temperature, jacket can be provided.

We have full range of Horizontal Filter Press from 8" to 33" as per below table

Model	Diameter of the table	No. of Plates	Filtration Area	Cake Holding Capacity	Flow rate	Pump Motor Rating
			m 2	Lit	LPH	KW
CSZH-0806	8”	6	0.217	4.9	600	0.75
CSZH-0808	8”	8	0.279	6.3	800	0.75
CSZH-1408	14”	8	0.819	24.75	1500	1.5
CSZH-1410	14”	10	1.001	30.25	1700	1.5
CSZH-1412	14”	12	1.183	37.75	1900	1.5
CSZH-1810	18”	10	1.65	55	4000	2.2
CSZH-1812	18”	12	1.95	65	4600	2.2
CSZH-1815	18”	15	2.4	80	5500	2.2
CSZH-1824	18”	24	3.75	125	8200	2.2
CSZH-2415	24”	15	4.192	144	7000	3.5
CSZH-2418	24”	18	5.035	171	8500	3.5
CSZH-2424	24”	24	6.625	225	12500	3.5
CSZH-3307	33”	7	4.176	118	7000	3.5
CSZH-3310	33”	10	5.736	163	10000	3.5
CSZH-3314	33”	14	7.821	222	13500	3.5
